The EKKO EK20D Diesel Forklift is designed to be used for all your material handling demands, warehousing, and distribution.
This unit is manufactured with high durable quality, Tier 4 EPA compliant with a Mitsubishi 4EG engine and competitive pricing.
The operation space is enlarged and heightened overhead guard and using large arc shape of the overhead guard's front leg
Multifunctional suspended seat increase the support of the driver, and reduce vibration, and balancing the weight of the driver.
Steering wheel adjusting mechanism is disposed in the appopriate position making it easily adjustable.
By using impedance composited muffler, this truck reduces the level of sound output.
Specifications
|
Model
|
|
EK20D
|
|
Drive type
|
|
Diesel
|
|
Type of operation
|
|
Propane
|
|
Load Capacity
|
LBS
|
4000
|
|
Load Center
|
in
|
24
|
|
Liftheight
|
in
|
185
|
|
Wheelbase
|
in
|
62.9
|
|
Service Weight
|
LBS
|
7716
|
|
Tire material
|
|
Solid Pneumatic Tire |
|
Wheel
|
|
7.00-12-12PR/6.00-9-10PR
|
|
Service Brake
|
|
Hydraulic Floor Pedal |
|
Overall width
|
in
|
45.2
|
|
Overall length with forks
|
in
|
141.8 |
|
Overall lengthwithout forks
|
in
|
96.8
|
|
Min ground clearance (at the mast)
|
in
|
4.3
|
|
Max traveling speed (loaded/unloaded)
|
mph
|
10.6/11.8
|
|
Mast Overall height
|
in
|
83
|
|
Free liftingheight
|
in
|
43.7
|
|
Overal Height w/ forks lifted
|
in
|
225 |
|
Fork Size
|
in
|
42.1x4.8x1.5
|
|
Battery
|
V/ Ah
|
12/80
|
|
Engine Mode
|
|
Mitsubishi 4EG
|
|
Engine rated power
|
HP/rpm |
Deisel 49/2250
|
